5000w Combo Deal

5000W E-Bike Combo Kit — Specifications

Top Speed

80–100 km/h (voltage, wheel size, rider weight dependent)

Power

5000W nominal

8000W peak (system dependent)

Battery Options (5000W rated)

72V (20S): 25Ah / 30Ah / 35Ah / 40Ah

Designed for high-current operation

Controller

72V 80A controller

Matched to motor and selected battery

Available in sinewave or squarewave (specify at checkout or in order notes)

Estimated Range (5000W average use)

• 72V 25Ah: ~22–32 km
• 72V 30Ah: ~26–38 km
• 72V 35Ah: ~30–40 km
• 72V 40Ah: ~35–50 km

Range varies with speed, throttle use, terrain, and rider weight.

What’s Included

• 5000W motor
• 72V 80A controller
• High-current motor/controller connector
• Standard throttle (or SurRon throttle if selected)
• Selected battery pack
• Battery discharge connector (matched to current load)
• Matching fast charger (voltage matched)
• Motor cut-off brake levers
• PAS system
• Installation manual & zip ties
• Bluetooth manual (if selected)

Charging

Fast charger included

72V → 84.0V

Bluetooth Smart BMS & App

Bluetooth-enabled smart BMS with mobile app

Real-time monitoring:

• Battery percentage & pack voltage
• Live current draw (amps)
• Individual cell voltages & balance
• Battery temperature
• Charge and discharge state

Battery Protection

• Over-charge
• Over-discharge
• Over-current
• Short-circuit
• Temperature protection

Default Configuration

Wheel size: 27.5”

Dropout width: 135mm

Any changes (wheel size, dropout width, controller type) must be written at checkout or in order notes. Orders without notes ship in standard configuration.
